Rock Splitter
Drawing of Splitter
| Unit / Model | CRS-80 | CRS-85 | CRS-95 | |
|---|---|---|---|---|
| Cylinder | Weight(kg) | 25 | 25 | 33 |
| Length(mm) | 770 | 770 | 800 | |
| Diameter(mm) | 80 | 85 | 95 | |
| No of Piston(ea) | 12 | 11 | 9 | |
| Piston Stroke(mm) | 23 | 24 | 25 | |
| Splitting Power(ton) | 1500 | 1500 | 1600 | |
| Operating Pressure(kg/cm2) | 1300 - 1500 | 1300 - 1500 | 1300 - 1500 | |
| Drilling Diameter(mm) | 89 | 89 - 95 | 102 - 105 | |
| No of Std. Piston(ea) | 4 | 4 | 4 | |
Drawing of Splitter
